AstroCell ll (Gasket Seal) AAF/CAMFIL/AMERICAN

AstroCell ll (Gasket Seal) AAF/CAMFIL/AMERICAN

PRICE TK10000.00 to 20000.00

As Per Required Dimension of Filter Price depend

Current Price Pls Contact WhatsApp: 01752848597

Category: HEPA & ULPA FILTERS: Tags: AstroCell ll (Gasket Seal), CAMFIL/AMERICAN, HEPA & ULPA FILTERS: Brand: AAF/CAMFIL/AMERICAN

Description
Reviews (0)

Description

HEPA & ULPA FILTERS:

Brand:AAF/CAMFIL/AMERICAN

Model: AstroCell ll (Gasket Seal)

Product Overview

● Individually tested for certified performance

● Reduces operating costs with lowest possible pressure drop from microglass media

● Available in a range of efficiencies

● Lightweight and compact

Specification

EN1822	H13 – U17
ISO 29463	ISO 35 H – ISO 75 U
Filter Depth (mm)	Various
Media Type	Fibreglass
Frame Material (Standard)	Aluminium
Separator Style	Hot Melt
Gasket Material (Standard)	PU Gel
Gasket Material (Optional)	Silicone Gel
Gasket Position	Downstream (BL), Upstream (RSC)
Faceguard	Both Sides
Special Size Available	Yes
Antimicrobial Available	No
Recommended Final Resistance	500 Pa
Max Operating Temperature	90ºC
Air Filtration Certificate	UL 900, FM 49201


H13 / ISO 35 H
M574-223-005	610 x 610 x 69	603	104
M574-223-008	610 x 1220 x 69	1,206
M574-223-538	1220 x 1220 x 69	2,411
M574-323-005	610 x 610 x 93	603	75
M574-323-008	610 x 1220 x 93	1,206
M574-323-538	1220 x 1220 x 93	2,411
M574-423-005	610 x 610 x 117	603	65
M574-423-008	610 x 1220 x 117	1,206
M574-423-538	1220 x 1220 x 117	2,411
H14 / ISO 45 H
M575-223-005	610 x 610 x 69	603	130
M575-223-008	610 x 1220 x 69	1,206
M575-223-538	1220 x 1220 x 69	2,411
M575-323-005	610 x 610 x 93	603	90
M575-323-008	610 x 1220 x 93	1,206
M575-323-538	1220 x 1220 x 93	2,411
M575-423-005	610 x 610 x 117	603	80
M575-423-008	610 x 1220 x 117	1,206
M575-423-538	1220 x 1220 x 117	2,411


U15 / ISO 55 U
M577-223-005	610 x 610 x 69	603	140
M577-223-008	610 x 1220 x 69	1,206
M577-223-538	1220 x 1220 x 69	2,411
M577-323-005	610 x 610 x 93	603	99
M577-323-008	610 x 1220 x 93	1,206
M577-323-538	1220 x 1220 x 93	2,411
M577-423-005	610 x 610 x 117	603	85
M577-423-008	610 x 1220 x 117	1,206
M577-423-538	1220 x 1220 x 117	2,411
U16 / ISO 65 U
M578-223-005	610 x 610 x 69	603	191
M578-223-008	610 x 1220 x 69	1,206
M578-223-538	1220 x 1220 x 69	2,411
M578-323-005	610 x 610 x 93	603	123
M578-323-008	610 x 1220 x 93	1,206
M578-323-538	1220 x 1220 x 93	2,411
M578-423-005	610 x 610 x 117	603	109
M578-423-008	610 x 1220 x 117	1,206
M578-423-538	1220 x 1220 x 117	2,411
